SCOUT

THE SCOUT - If you're on the fence about picking up your first DIY enclosure, this is a great option. The Scout is simple, easy to travel with, compact, and still offers the custom options of our top tier premium enclosures. Get in the game without breaking the bank.

JOYSTICK AND ALL-BUTTON OPTIONS (Email contact@mtnheirco.com if you don't see your preferred button layout or would like a custom layout.)

SELECTION BUTTONS (Options Available)

These are the (3) 24mm button holes commonly used for Home/Select/PlayStation or L3/R3/Track-Pad, and can be added anywhere on the sides of the enclosure. The default option for these (3) button holes will be located on the back, right of the pass-through port. If you would like to change the location, prefer 30mm, or add more button holes, please email us after completing your purchase. (contact@mtnheirco.com). Also, NOTE, if you choose not to have the selection buttons on the back, we will delete the finger indentions to maintain a clean line on the top panel.

SPECS

• 14.5" x 7.5" x 2.5"
• 3.5 lbs. (1.85 kg)
• The Highest Quality Laser Cut Acrylic Construction
• 1/8" interlocking subframe wrapped in 1/8" artwork cover panels

MATERIAL

• Enclosure Sub-Frame is 1/8" acrylic material
  • Interlocking corners and keyholes cut to make assembly quick and easy
  • Sub-Frame top panel holes cut for mounting your joystick and PCB

  • Holes are recessed so that the artwork cover panels lay perfectly flat
  • Sub-Frame color options include Clear, White, or Matte Black
• Clear cover panels are clear 1/8" acrylic and wrap all sides/top & bottom of the enclosure.
• Note: All acrylic panels are covered in protective paper or plastic film to ensure the pieces arrive free of scratches

ARTWORK TEMPLATES

• Templates will be emailed to you following the shipment of your enclosure
• We'll provide the the artwork template in Adobe Photoshop file format with instructions.
• We're not currently offering a print and cut service just yet but will in the future. Stay tuned!

ALSO INCLUDED

• PCB mounting hardware for Brook Gaming PCB/fighting boards, GP2040 boards as well!
• Rubber non-slip feet (bottom)
• Neutrik USB mounting hardware nuts and bolts
• Top, bottom, and side panel nuts and bolts
• Joystick mounting nuts and bolts

SHIPPING | United States only at this time

• All orders will be processed and shipped within 2-3 business days
• Tracking info will be provided upon shipment
